Industrial Computer Systems

Intel Q670

Intel Q670

2/13/6/4

1 x VGA: Up to 1920 x 1200 @ 60Hz
1 x DVI: Up to 1920 x 1200 @ 60Hz
1 x HDMI: Up to 4096 x 2160 @ 30Hz

2 x PCI-E x16 Slot (1 x PCIe x16 Gen.4 or 2 x PCIe x8 Gen.4)
3 x PCI-E x4 Slot (PCIe x4 Gen.4)
1 x PCI-E x4 Slot (PCIe x4 Gen.3)
1 x PCI Slot
1 x M.2 (Key-E, 2230, PCIe + USB 2.0 + CNVi, Wifi + BT)

-

-

1 x HDMI: Max resolutions up to 4096 x 2160 @ 60Hz
1 x eDP/LVDS: eDP: Max resolutions up to 2560 x 1600 @ 60Hz LVDS: Max resolutions up to 1920 x 1200 @ 60Hz
1 x LVDS/MIPI: LVDS: Max resolutions up to 1024 x 768 @ 60Hz MIPI: Max resolutions up to 1920 x 1080 @ 60Hz

1 x Mini-PCIe (Wifi/3G/4G)
1 x M.2 (key-B, PCIe 3.0/ PCIe 2.0/ USB 3.0/ SATA, 2242/3052)

-

-

1 x HDMI: Max resolutions up to 4096 x 2160 @ 60Hz
1 x eDP: Max resolutions up to 4096 x 2160 @ 30Hz
1 x LVDS/eDP: Dual 24 bit, up to 1920 x 1080 @ 60Hz
eDP up to 4096 x 2160 @ 30Hz

1 x Mini-PCIe (3G/4G, with 1 x Full size SIM card slot)

-

-

1 x HDMI: Max resolutions up to 4096 x 2160 @ 60Hz
1 x eDP: Max resolutions up to 4096 x 2160 @ 30Hz
1 x LVDS/eDP: Dual 24 bit, up to 1920 x 1080 @ 60Hz
eDP up to 4096 x 2160 @ 30Hz

1 x Mini-PCIe (3G/4G, with 1 x Full size SIM card slot)

Intel SoC integrated

Intel SoC integrated

1 x HDMI (Up to 4096 x 2160 @ 30Hz)
1 x LVDS (Up to 1920 x 1200 @ 60Hz)
1 x eDP (Up to 1920 x 1200 @ 60Hz, eDP1 is Option and eDP2 is exist)

1 x M.2 Key-E Slot (Wifi + BT, 2230)
1 x M.2 Key-B Slot (4G for 3042, 5G for 3052)

Intel H310

Intel H310

2 x HDMI (Up to 4096 x 2160 @ 24Hz)
1 x Display Port ++ (Up to 4096 x 2304 @ 60Hz)
1 x LVDS (Dual Channel 24bit, up to 1920 x 1200 @ 60Hz)
1 x eDP (Up to 4096 x 2160 @ 60Hz)

1 x PCIe (x4) slot
1 x M.2 (Key-B, 3042-4G, 3052-5G)
1 x M.2 (Key-E, 2230, Wifi + BT)

Intel Q170

Intel Q170

1 x HDMI 1.4 (Up to 3840 x 2160 @ 30Hz)
1 x Display Port 1.2 (Up to 4096 x 2304 @ 60Hz)
1 x LVDS (Up to 1920 x 1200 @ 60Hz)

Mini PCIe Half size (PCIe/USB)
Mini PCIe Full / Half size (PCIe/USB/SATA)
PCIe x4 (Gen. 3) slot

Intel H110/Q170

Intel H110/Q170

1 x HDMI 1.4 (Up to 3840 x 2160 @ 30Hz)
1 x Display Port 1.2 (Up to 4096 x 2304 @ 60Hz)
1 x LVDS (Up to 1920 x 1200 @ 60Hz)

Mini PCIe Half size (PCIe/USB)
Mini PCIe Full / Half size (PCIe/USB/SATA)
PCIe x4 (Gen. 3) slot

Intel SoC integrated

Intel SoC integrated

1 x VGA (Up to 1920 x 1200 @ 60Hz)
1 x HDMI (Up to 3840 x 2160 @ 30Hz)
1 x LVDS (Up to 1920 x 1200 @ 60Hz)

1 x Mini PCIe (1 x Wifi/3G/4G, with 1 x SIM card Header)
1 x M.2 Key-E Slot (Wifi+BT, 2230)

Intel SoC integrated

Intel SoC integrated

1 x VGA (Up to 1920 x 1200 @ 60Hz)
1 x HDMI (Up to 1920 x 1200 @ 60Hz)
1 x LVDS (Up to 1920 x 1200 @ 60Hz)

2 x Mini PCIe (1 x mSATA, 1 x Wifi/3G/4G)
