Fanless Box PC

Home - Products - Industrial Computer Systems - Fanless Box PC
Filter:
CPU Type
Apply
Reset
Filters Sort results
Reset Apply
Model
CPU
Chipset
I/O
Expansion
Storage
NEWTBOX-J6412
Intel Celeron J6412
SoC Integrated
2 x RS-232, 2 x LAN, 3 x USB 3.0, 3 x USB 2.0, 2 x HDMI, 1 x GPIO

1 x M.2 (Key-M, 2280, PCIe x2 NVMe/ SATA) NVMe is default
1 x M.2 (Key-B, 3052, PCIE/USB 3.0 + USB 2.0) USB 3.0 is default
1 x Mini-PCIe (PCIe + USB 2.0/ mSATA) mSATA is default
1 x 8-bit GPIO (Optional)
2 x COM, 2 x LAN, 2 x PoE, 2 x USB (Optional as expansion area)
6 x Antennas holes for Wifi/BT/3G/4G/5G (Optional)
1 x SATA 3.0, 1 x NVMe M.2, 1 x mSATA
NEWTBOX-J6412-4C
Intel Celeron J6412
SoC Integrated
3 x RS-232, 1 x RS-232/485, 2 x LAN, 3 x USB 3.0, 3 x USB 2.0, 2 x HDMI, 1 x GPIO

1 x M.2 (Key-M, 2280, PCIe x2 NVMe/ SATA) NVMe is default
1 x M.2 (Key-B, 3052, PCIE/USB 3.0 + USB 2.0) USB 3.0 is default
1 x Mini-PCIe (PCIe + USB 2.0/ mSATA) mSATA is default
1 x 8-bit GPIO (Optional)
2 x COM, 2 x LAN, 2 x PoE, 2 x USB (Optional as expansion area)
6 x Antennas holes for Wifi/BT/3G/4G/5G (Optional)
1 x SATA 3.0, 1 x NVMe M.2, 1 x mSATA
NEWTBOX-TGL-4C
Intel 11th Gen. Tiger Lake processor
SoC Integrated
3 x RS-232, 1 x RS-232/485, 2 x LAN, 6 x USB 3.0, 2 x HDMI, 1 x GPIO (Optional)

1 x M.2 Key-M Slot (PCIe x4 NVMe / SATA SSD, 2280)
1 x M.2 Key-E Slot (PCIE + USB 2.0, Support Wifi + BT, 2230)
1 x Mini PCI-E Slot (PCIE +USB 2.0, Support Wifi +3G/4G, with 1 x nano-SIM card slot)
1 x 8-bit GPIO (Optional)
2 x COM, 2 x LAN, 2 x PoE, 2 x USB (Optional as expansion area)
6 x Antennas holes for Wifi/BT/3G/4G/5G (Optional)
1 x SATA 3.0 7P Connector (with 1 x SATA power header)
NEWTBOX-TGL
Intel 11th Gen. Tiger Lake processor
SoC Integrated
2 x RS-232, 2 x LAN, 6 x USB 3.0, 2 x HDMI, 1 x GPIO (Optional)

Support PCIe x4 Gen.4 NVMe SSD, Gen.3 for Celeron 6305E
1 x M.2 Key-M Slot (PCIe x4 NVMe / SATA SSD, 2280)
1 x M.2 Key-E Slot (PCIE + USB 2.0, Support Wifi + BT, 2230)
1 x Mini PCI-E Slot (PCIE +USB 2.0, Support Wifi +3G/4G, with 1 x nano-SIM card slot)
1 x 8-bit GPIO (Optional)
2 x COM, 2 x LAN, 2 x PoE, 2 x USB (Optional as expansion area)
6 x Antennas holes for Wifi/BT/3G/4G/5G (Optional)
1 x SATA 3.0 7P Connector (with 1 x SATA power header)
NEWTBOX-WKL
Intel 8th Gen. Whiskey Lake processor
SoC Integrated
2 x RS-232, 2 x LAN, 4 x USB 3.0, 2 x HDMI, 1 x GPIO (Optional)

1 x M.2 Key-M/B (PCIe x4 NVMe/SATA SSD, 2242/2280)
1 x M.2 Key-B Slot (3042/3052, PCIE +USB3.0 +USB2.0, support 4G/5G, with 1 x SIM Card Header)
1 x M.2 Key-E Slot (PCIE +USB 2.0, Support Wifi/BT, 2230)
1 x 8-bit GPIO (Optional)
2 x COM, 2 x LAN, 2 x PoE, 2 x USB (Optional as expansion area)
6 x Antennas holes for Wifi/BT/3G/4G/5G (Optional)
1 x SATA 3.0 7P Connector (with 1 x SATA power header)
TBOX-i5-7200U
Intel Core i5-7200U
SoC Integrated
2 x RS-232, 2 x LAN, 2 x USB 3.0, 6 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-i5-7200U-4C
Intel Core i5-7200U
SoC Integrated
4 x RS-232, 2 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-i5-7200U-4L
Intel Core i5-7200U
SoC Integrated
2 x RS-232, 4 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-i3-6100U
Intel Core i3-6100U
SoC Integrated
2 x RS-232, 2 x LAN, 2 x USB 3.0, 6 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-i3-6100U-4C
Intel Core i3-6100U
SoC Integrated
4 x RS-232, 2 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-i3-6100U-4L
Intel Core i3-6100U
SoC Integrated
2 x RS-232, 4 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-J1900
Celeron J1900
SoC Integrated
2 x RS-232, 2 x LAN, 1 x USB 3.0, 7 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-J1900-4L
Celeron J1900
SoC Integrated
2 x RS-232, 4 x LAN, 1 x USB 3.0, 3 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-J1900-4C
Celeron J1900
SoC Integrated
3 x RS-232, 1 x RS-232/485, 2 x LAN, 1 x USB 3.0, 3 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-N3350
Celeron N3350
SoC Integrated
2 x RS-232, 2 x LAN, 2 x USB 3.0, 6 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO, 1 x Audio

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-N3350-4L
Celeron N3350
SoC Integrated
2 x RS-232, 4 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO, 1 x Audio

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
TBOX-N3350-4C
Celeron N3350
SoC Integrated
4 x RS-232, 2 x LAN, 2 x USB 3.0, 2 x USB 2.0, 1 x VGA, 1 x HDMI, 1 x GPIO, 1 x Audio

2 x Mini-PCIe (1 x mSATA, 1 x Wifi/3G/4G supported)
2.5" SATA HDD, mSATA
MF-J1900-801WC5-TVS
J1900
SoC integrated
2 x RS-232, 3 x RS-232/422/485, 2 x LAN, 2 x USB 3.0, 4 x USB 2.0, 1 x VGA, 1 x HDMI

1 x Half size Mini-PCIe
1 x PCIe (x1) slot
1 x mSATA with SATAII (shared)
2.5" SATA HDD, mSATA
MF-J1900-801WC5
J1900
SoC integrated
2 x RS-232, 3 x RS-232/422/485, 2 x LAN, 2 x USB 3.0, 4 x USB 2.0, 1 x VGA, 1 x HDMI

1 x Half size Mini-PCIe
1 x PCIe (x1) slot
1 x mSATA with SATAII (shared)
2.5" SATA HDD, mSATA
MF-J1900-801
J1900
SoC integrated
4 x RS-232, 2 x LAN, 2 x USB 3.0, 4 x USB 2.0, 1 x VGA, 1 x DVI-I

PCIe 2.0 x1 slot
Mini PCIe Full / Half size
2.5" SATA HDD, mSATA
